Product Details
＋
| Product Attribute | Attribute Value |
|---|---|
| Backlighting | Backlight |
| Communication | RS232C, RS485, RJ45 |
| Dimensions | 119.4 L x 63 W mm |
| Display Colors | Color |
| Display Resolution | 120 x 32 Pixels |
| Display Size | 2.9 Inch Display |
| Family Name | Magelis HMI & iPC Family |
| For Use With | PLC |
| HMI Type | Touch Screen HMI |
| Length | 4.701" (119.4mm) |
| Maximum Operating Temperature | 55 C |
| Minimum Operating Temperature | 0 C |
| Mounting Type | Chassis Mount |
| Number of Ports | 2 Port |
| Port Style | RS232C, RS485, RJ45 |
| Primary Type | Operator Interface |
| Resolution, Display | 122 × 32 |
| Series | |
| Size, Screen | 72 × 20 mm |
| Supply Voltage | 5VDC |
| Technology | TFT LCD Display |
| Temperature Operating Range | 0 to 55 C |
| Type | Monochrome |
| UPC Code | 785901299134 |
| Voltage Rating | 5 VDC |
| Width | 2.48" (63mm) |
Overview
Schneider Electric Magelis XBT Series - XBT GC HMI Controller & Accessories for Magelis HMIs:
The Magelis XBT GC HMI Controller combines human machine interface and control system functions in a single product. It responds to the stringent requirements of online, compact machines, in line with the flexible machine control approach. The high level of integration makes it extremely compact while simplifying control system equipment. Highly economical, this product helps reduce costs throughout the life cycle of your machines, regardless of production run length or the level of customization.
Features:
